| Model | ZZ1257V464JF1（Euro5） | ZZ1257V584JF1（Euro5） | |
| Weight | Curb Weight | 10,250 kg | 9600 |
| Gross Vehicle Weight | ≤39,000 kg | 33000 | |
| Dimensions | Overall Dimensions (LxWxH)(M) |
10.77*2.5*3.135 | 11.69*2.5*3.15 |
| Wheelbase (mm) | 5225+1350 | 5825+1350 | |
| Front Overhang(mm) | 1550 | 1550 | |
| Rear Overhang (mm) | 2645 | 2965 | |
| Drive type | 6X4 | ||
| Cab | HOWO-NX Cab Single Refrigeration A/C Manual Cab Tilting Automatic Lifting Window Four-point Hydraulic Suspension Cab Two-Level Stepping Board Hydraulic Suspension Driver Seat |
||
| Engine | Model | MC11.36-50 | MC07.28-50 |
| Displacement | 10.518L | 6.87L | |
| Power | 360HP | 280HP | |
| Type | six cylinders in line, water-cooling, four-stroke, turbo charger with inter-cooler, direct injection | six cylinders in line, water-cooling, four-stroke, turbo charger with inter-cooler, direct injection | |
| Emission standard | Euro V | Euro V | |
| Transmission | HW19709XSTL, synchromesh, 9 Forwards & 1 Reverse Shifts, hydraulic retarder | HW13709XSTC2, synchromesh, 9 Forwards & 1 Reverse Shifts, hydraulic retarder | |
| Chassis frame | double-layer frame (8+5/300) | ||
| Front axle | VGD71（drum-type） 7T | VGD71（drum-type） 7T | |
| Rear axle | MCX16ZG double axles (i=5.451) 16T*2 | MCX16ZG double axles (i=5.451) 16T*2 | |
| Suspension | front and rear strengthened leaf spring (10/12) | ||
| Fuel Tank | 400L | ||
| Tyre | 11.00R20 | ||
| Performance | Max Speed (km/h) | 102km/h | |
| Max Gradeability (%) | 20% | 30% | |
| Protections | Type | Metal Bumper | |
| Upper Body | N/A | N/A | |
